Passenger Lift Installation, Maintenance and Repair
Omega Lifts offer passenger lift systems to fit any possible application. The choice of system along with unit size and shape, is based on your individual needs and requirements.
Lifts are usually manufactured in standard, pre-engineered sizes to keep costs down, but we have the expertise to offer custom designs that meet both your specific needs and current building regulations. Our installation team works closely with you to ensure the final product exceeds your expectations. We take great pride in helping you plan and carry out successful projects by providing a first class customer service and an unrivalled personal touch.
From low-rise economy models to high-speed lifts serving multi-floor office buildings, we can provide an installation solution for any application.
There are a number of types of passenger lift systems available, please do get in touch if you need more advice.
Hydraulic Lift With Motor Room
A complete range of hydraulic lift packages is offered, covering applications from small passenger lifts up to panoramic and large goods lifts.
- Compliance with EN 81 regulations and directive 95/16/ΕC
- Capacity range from 200 kg to 20.000 kg
- Speed up to 0.9m/sec
- Travel up to 28m (10 stops)
- Low noise and smooth operation
- Stiff structure
- Standard Automatic Emergency Operation
- Motor room at any location with reference to the lift shaft
Hydraulic MRL Lift (Machine Room Less)
HYDRO MRL, where all the motor room equipment is fitted into a metal cabinet and the HYDRO TOTAL MRL, where the tank of the power unit is placed into the shaft pit whilst the controller and the valve block are fitted into a stainless steel cabinet adjacent to the landing door post.
- Compliance with EN 81 regulations and directive 95/16/ΕC
- Capacity range from 200 kg to 2.000 kg
- Speed up to 0.9m/sec
- Travel up to 18m (7 stops)
- Low noise and smooth operation
- Stiff structure
- Standard Automatic Emergency Operation
Traction Lift With Machine Room
The development of the electronic driving of lift motors (VVVF), together with the demand for long travels, brought the classic traction lift again into the market. Following a policy of qualitative choices, a complete range of traction lift packages is offered, satisfying all kind of applications.
- Compliance with EN 81 regulations and directive 95/16/ΕC
- Capacity range from 200 kg up to 5.000 kg
- Speed up to 1.6m/sec
- Travel up to 100m (32 stops)
- Low noise and smooth operation
- Stiff Structure
- Automatic emergency operation
Traction MRL Lift (Machine Room Less)
The MRL Traction Lift eliminates the disadvantage of the classic traction lift, which is the need of a machine room. The MRL traction machine is fitted inside the shaft whilst the controller is fitted in a stainless steel cabinet adjacent to the top floor landing door post.
Two different configurations are offered; The BASIC MRL, which is an economic choice with direct suspension and a two speed or VVVF geared motor and the ECO MRL, which is the ultimate choice with indirect 1:2 suspension and VVVF encoder controlled gearless motor.
- Compliance with EN 81 regulations and directive 95/16/ΕC
- Capacity range from 450 kg up to 2.000 kg
- Speed up to 1.6m/sec
- Travel up to 100m (32 stops)
- Low noise and smooth operation
- Stiff structure
- Standard automatic emergency operation
